Hello to everyone. Today I want to talk about Tech 2 memory card. I don’t fully understand how to test. In fact, not often but sometimes get a bad card, visually for him not to say anything, even putting them in the Tech 2 they will be loaded. But on some menu Tech 2 Scanner will just restart. I have it booted from the menu on the device, specifically in the Hardware version. With 99% probability he would hang in the engine block Engine Data 1…3. Not always, but sometimes he wrote ADDRESS ERROR – PROCESSOR HALT. Later I bought another card, it didn’t hang, then I copied the software to both had the same version, eventually worked correctly only 1 card, or other periodically rebooted the device or just all hung, helped turn off – turn off the car diagnostic scanner Tech 2.

7-17-2

Here is a photo of my bad card may still try to solder, who knows things worse for it clearly will not. Yes, and to override the card is best to use any laptop or desktop computer with PCMCIA, as the Tech2 Scanner this is often time consuming, and pieces not entirely successful cases.

Posted in Uncategorized | Comments Off on 1

How to Used SKP900 Program Chevy Sonic 2014 Remote Key

Here’s the step by step instructions on how to program a remote head key for a 2014 Chevy Sonic using SuperOBD SKP900 auto key programmer.

4-button remote key

Connect SKP-900 host with vehicle via OBD diagnostic socket using main test cable

Turn ignition switch to ON position

Turn on skp900 v5.0

Select Immobilizer->Chevrolet->Immobilizer 2->New Structure->Loading…->IMMO System

Choose OBDII adapter and turn ignition off

SKP900 detect current number of key: 1

Select Program Key

Turn ignition on

SKP900 key programmer will require to enter 4-digit pin code to access

Manually enter pin and confirm

Programming, please wait for 10 minutes

Turn ignition off and add a new key

Open-close driver door, shut down all electronic equipment

Turn ignition on

Continue to program next key.

Turn ignition off and add extra key

Insert a new key and turn ignition on

Repeat procedure above until key programming is done

Programming succeed.

Test the remote key, working!

Note: SKP900 is out of production. You can choose other alternative/s, Xtool X100 Pad2, OBDSTAR X300 DP or Lonsdor K518ISE key programmers.

http://www.fobdii.com

Posted in Auto Key Programmer | Tagged , , | Comments Off on How to Used SKP900 Program Chevy Sonic 2014 Remote Key

Updated to V3.8.0 XHORSE VVDI MB TOOL ADD SPANISH LANGUAGE

Xhorse VVDI MB BGA TOOL have updated to V3.8.0, Add Spanish language and support load Motorola EEPROM dump in EIS window,Support read VIN and EIS part number for Kline EIS and Bugfix. No need update Fireware.

Latest V3.8.0 VVDI MB BGA Tool

1. Frequently update for more and more functions
2. Now support all key lost : w204, w207,W166, W246, W212, W212(old),some W216, W164 2009- and some others
3. Mainly used for key reading and writing,EIS tools,password calculation,key file preparing,ESL tools,ECU/Gearbox renew and many special functions

VVDI MB BGA TOOL  V3.8.0 Update details:
************************************************* *********************
*** 2018-02-26
*** Require firmware V3.6.0
************************************************* *********************
===== BENZ V3.8.0 =====
1. Support spanish language
2. Support load Motorola EEPROM dump in EIS window and display key information
3. Bugfix for read KM in some W207 EIS
4. Bugfix for old motorola keys show incorrect key password
5. Support read VIN and EIS part number for Kline EIS(OBD communication require short connect PIN7 and PIN1)
6. Bugfix

Xhorse V3.8.0 VVDI MB BGA Tool Auto Key Programmer download link:https://mega.nz/#!iwoWmILA!JYgYsMSPg3cQjhxTn7wdEuwPRPwpxxkjIcnkFZjVgzE
VVDI MB TOOL V3.7.0 update detail:

Require firmware V3.6.0

===== BENZ V3.7.0 =====

1. Bugfix for some countries can’t synchronize with server
2. Bugfix for old motorola keys show incorrect key password
3. Bugfix
http://www.fobdii.com

Posted in Auto Key Programmer | Tagged , , | Comments Off on Updated to V3.8.0 XHORSE VVDI MB TOOL ADD SPANISH LANGUAGE

How To Solution SD Connect C4 DCDI_eErrorCode=204 errer ?

To solve SD Connect C4 Error Code 204, just put fresh 6 battery and do a csd firmware update. This is a common problem with cheap SD C4.

In detail…

The error message: DCDI_eErrorCode=204 (204)

sdconnect-c4-error-code-204-2
sdconnect-c4-error-code-204-1

Solved … was the 6 x AA battery into the MB Star Diagnostic Tools

This is the how-to’s of…

  1. Please prepare the following tools:

how-to-install-sdconnect-c4-battery-Picture1

①— MB SDConnect C4 multiplexer which need to input the batteries.

②— 6 units Ni-MH Rechargeable batteries, Size: AA, Voltage: 1.2V, Capacity: above 1700mA.

③— 1 unit 108M WIFI Card.

④— Plum screwdriver, Specification: T-20

  • Take out the rubber:

2.1 Use the T20 Plum screwdriver to take out the screws as below.

how-to-install-sdconnect-c4-battery-Picture2

2.2 Take out the rubber as below.

how-to-install-sdconnect-c4-battery-Picture3

①— Batteries Space.

②— WIFI Card Space.

③— SD Card Space.

  1. Insert the Rechargeable batteries.

3.1 Use the T20 Plum screwdriver to take out the screws of Batteries Space fixation as below.

how-to-install-sdconnect-c4-battery-Picture4

3.2 Take out the fixation of Batteries Space. Pay attention to the Battery polarity marked in the Batteries Space.

how-to-install-sdconnect-c4-battery-Picture5

3.3 Insert the batteries. Note the Battery polarity.

how-to-install-sdconnect-c4-battery-Picture6

3.4 Button on the Fixation of Batteries Space after inputting the Rechargeable batteries.

how-to-install-sdconnect-c4-battery-Picture7

3.5 Use the T20 Plum screwdriver to fix the screws of Batteries Space fixation as below. Inserting the batteries is finished.

how-to-install-sdconnect-c4-battery-Picture8

  1. Installing WIFI Card.

4.1 Inserting the WIFI Card into the WIFI Card Space. Please make the correct direction.

how-to-install-sdconnect-c4-battery-Picture9

4.2 Push it to make it totally connected.

how-to-install-sdconnect-c4-battery-Picture10

4.3 Cover the rubber and fix the screws to finish all the work.

how-to-install-sdconnect-c4-battery-Picture11

Note 1:

Go to the info section within DAS Xentry— search SDconnect and you will find what all the SDconnect symbols defined!!

Note 2:

pls check these picture, you can choose self-diagnosis your MB SDConnect Compact 4

sdconnect-c4-self-diagnosis-1
sdconnect-c4-self-diagnosis-2
sdconnect-c4-self-diagnosis-3

http://www.fobdii.com/category-15-MB-Star-Diagnostic-Tools.html

Posted in MB Star Diagnostic Tools | Tagged , , | Comments Off on How To Solution SD Connect C4 DCDI_eErrorCode=204 errer ?

How To used GM Tech2 scanner turn off SAAB day running lights ?

I have got a clone GM tech2 after hearing it is less than $300 and is able to do diagnosis and coding. Used it to reset day running light on my 2004 SAAB the other day. Worked as it should be. I saw some forum members are looking for a way to complete turn off the DRLs and would like to share a simple guide about this with the Tech2 scanner.

Tech2 Diagnostic Scanner with TIS2000 for GM, is a very good tester used to diagnose GM vehicles. The Vetronix Tech 2 contains Authentic GM software and provides support for on-board diagnostics on all GM systems 1992 thru 2011. TIS2000 supports till 2007 year GM car programming,supports GM/SAAB/OPEL/SUZUKI/ISUZU/HOLDEN.
GM Tech2 scanner
Tools you will need:

GM Tech2 scanner for GM and SAAB
32MB PCMCIA Card for Tech2
A SAAB car (Here take my daughters 2004 SAAB for example)

How to:

Hook up Tech2 to the OBD2 port in your car. The scanner does not need software installation and can be used directly after connecting it to your car.

Insert 32MB card into Tech2
Run Tech2 diagnostic tool
Go to Diagnostic Mode
Select Diag >2003 >9-3 Sport Select Body>Exterior Lighting and Horn
Low beam adjustments
F0. Auto Low Beam also in Pos 0
Change setting to NO
Wait several seconds until the lights flicker and go out
Exit
Go to Fog Lights Front
Change to Position 1 & 2 ROW (Rest of World) Program and click Exit when finished.

After the programming, you will get:

Pos 0 > No Lights
Pos1 > Fogs and 5 Watt Headlamp / Parking Light
Pos3 > Low Beam, High Beam, Manual Control of Fogs

This process takes about 5 minutes. You can also turn the lights on following this process.

http://www.fobdii.com

Posted in Car Diagnostic Tool | Tagged , , , | Comments Off on How To used GM Tech2 scanner turn off SAAB day running lights ?

How To Used Lonsdor K518ISE read Peugeot 308 2017 Pin Code by OBD

Lonsdor K518ISE key programmer has successfully read 4-digit pin code on a Peugeot 308 year 2017 by OBD within 5 seconds.

Lonsdor K518ISE  Auto Key Programmer universal auto key programmer , with wider vehicle coverage in key programming, it is customized as the first masterpiece to the overseas market from Lonsdor. With months of preparation and rigorous testing, from the software design to the user experience, it is an epitomize of Lonsdor years of industry experience. It is tailored and perfect for vehicle locksmith, to help making their work easier, faster and more powerful!

Lonsdor K518ISE Key programmer Special Features:

Volvo (S40, S60, S80, XC60, XC90, C30, C70, V40, V60, V70) key programming.
Toyota/Lexus: smart key all key lost – via OBD ( without dismantle)
BMW CAS3/CAS3+/CAS3++: direct OBD programming
BMW CAS4/CAS4+: dismantle & read data programming
BMW FEM system key programming & All keys lost
2016 -New Maserati: smart key programming
2016 -New Ford: smart key programming
Hyundai / Kia 46/47/8A smart key: PIN code reading via OBD, all key lost included.
Renault ( Megane, Koleos, Scenic) without PIN code key programming
VAG group 4th & 5th immobilizer system
Ferrari (458, F12, F149): direct OBD programming
Peugeot /Citroen: two ways to read PIN code & programming, all keys lost included.

Connect K518 host with vehicle via OBD diagnostic socket

Select Immobilizer->Peugeot->Read Pin Code->Type 1

lonsdor-k518-peugeot-308-pin-1

lonsdor-k518-peugeot-308-pin-2

lonsdor-k518-peugeot-308-pin-3

Insert a working key and turn ignition switch to ON position

lonsdor-k518-peugeot-308-pin-4

lonsdor-k518-peugeot-308-pin-5

Reading pin code in progress

lonsdor-k518-peugeot-308-pin-6

Lonsdor K518 read Peugeot 308 2017 4-digit pin code success

lonsdor-k518-peugeot-308-pin-7

http://www.fobdii.com/wholesale-780-lonsdor-k518ise-key-programmer.html

Posted in Auto Key Programmer | Tagged , , | Comments Off on How To Used Lonsdor K518ISE read Peugeot 308 2017 Pin Code by OBD

How To Free Download Xhorse VVDI Remote Chinese Database

Download Xhorse VVDI2 remote database will help solve error E0-94 while making remotes.

Top 5 Reasons to Get VVDI2 Commander Key Programmer

1. This VVDI2 comes with Basic Function + VW + Porsche+ AUDI Generation 5 function+BMW OBD Fucntion+BMW CAS4 function ,No Need to buy other Authorization. You may only need the cas plug to work with vvdi2
2. VVDI2 Covers All the Functions of VVDI, VVDI 5th IMMO Adapter, BMW Multi Tool, CAS4 Adapter, Most functions of Tango, J2534
3. Support VW, Audi, BMW and Porsche
4. Provide Exchange Service for Old VVDI,Item number: SV86-1
5. Newest Version: V5.2.5
6. Pls note VVDI2 FULL not include the vag 48 copy and BMW FEM authorization. Need to buy extrally if you need

Choose Autorization when receive the label as follow.

0=(VK-01) key programmer

1=(VJ-01) Passthru J2534
2=(VV-01) VW 4th
3=(VV-02) VW 5th
4=(VB-01) BMW OBD Function
5=(VB-02) BMW CAS4 Function
6=(VP-01) Porsche

sv86-1-vvdi2-authorization

Problem:

I am having Error E0-94 while making remotes!!!

I bought a bunch of remotes some time ago and there were no mentioning if they are China or EU remotes! Now that Samic has changed my default data base to EU now my remotes will not work because they are China!????? So that means i have to throw them out!???? Is this how it should work!?

Would be glad if someone can post here the Chinese remote data base so i can still use my already bought (it looks like Chinese version) remotes.

P.S. Would be glad if someone can post here the Chinese remote data base so i can still use my already bought (it looks like Chinese version) remotes.

Solution:
if your VVDI2 Auto Key Programmer have china data base , and you use EU remote – this is normal
also in reverse way
you must use Eu remote + customize VVDI to EU

or use Chinese remote and keep china database.

if you install new software , system automatically download Chinese database.
you must delete file, connect VVDI2 key programmer, run software and proper database will be downloaded.
if you have already Chinese data base , not always can be overwrite.

link for all if you need to use this database need to close internet connection in C/Program Files/VVDI2/Transponder Programmer/Database -delete your file remote database and put this

https://mega.nz/#!FkIDQbhK!VT_Hq6nbUuuL_r1aLzCcsN66EyUat0kQtjwW4I9WRbU

Feedback:

Thanks! This solution works and now i can still use my remotes without need to buy new EU remotes.

FYI:

How to customize remote Database to EU (English)?
Contact seller and request to change your VVDI2 serial number to region when you are.

Posted in Auto Key Programmer | Tagged , , | Comments Off on How To Free Download Xhorse VVDI Remote Chinese Database

GM TECH2 or GM Nano which is best Troubleshoot the BCM on the 1996 OBD2 Vettes?

Looking for Chinese GM Tech2 scanner to troubleshoot the BCM on the 1996 OBD2 Vettes, purpose is to cycle the ABS pump, diagnose air bag module among other things.

Budget is supposed to be around $350.00 and if it doesn’t last that long at least it’s cheaper than the thousands.

Optional GM scanner tools:

a used Tech 2 original (Price depends on)

GM Tech2 Chinese ( $240-$330)

GM VXDiag Nano  ($115 with wifi, $105 USB connection)

Here we go for their reviews

  1. a used Tech 2 original will not be mentioned here, since everyone knows it is best, for the used one, you can try at your own lucky.
  2. GM Tech2 Chinese reviews

GM Tech ii scanner Features:

1) GM software in the Tech 2 Flash means the most comprehensive diagnostic software available for late model GM vehicles.
2) Support for on-board diagnostics on all GM systems 1992 thru current year.
3) Removable hardware modules provide insurance against scan tool obsolescence.
4) Large, easy-to-read backlit screen.
5) RS232 & RS485 ports provide the avenue to connect future devices to your Tech 2 Flash.
6) Ability to capture stored DTCs, Freeze Frame, and Failure Record for later review.
7) Ability to view the status of vehicle diagnostic tests as they run.
8) Bi-directional The authentic GM 1992-current year software will provide full bi-directional control when performing power train, chassis, and body diagnostics.

1) It says it covers most 1991 to 2013 GM cars.

I just bought one off Ebay and I am going to give it a try. I purchased it from a US seller but there are others from China. I contacted the seller and asked if it would cycle the ABS pump on a 1996 Corvette and other body control module diagnostics, he said that it would.

It does come with the 32 Mb flash card for GM. He has Saab and Isuzu cards and they are $60.00 each.

2) I have used the Tech2 Chinese I purchased for numerous ABS ,BCM as well as ECM / PCM concerns on a wide variety of GM OBD II platforms………..

As you know, the title doesn’t specify which year and model of GM, the following parts take C6, 07 2500 GMC for example.

I have my C6, 07 2500 GMC, 09 Cobalt that it will work on. Have another scan tool for our foreign cars.

Surprises were, this thing is bigger than I thought. It’s a foot tall by 6″ wide. It needs the velcro straps it comes with.

Tested it on my GMC truck and all seems fine. Connector for older OBD1 as well for 91-95,6 too. Latest software for GM 33.004.

The memory card works in either slot, I tried both although the disc says to install in upper slot. It’s a tight fight because the spring loaded door doesn’t quite open enough for the card to slide in easily. I got it in with a touch of prying. Not a big deal.

Entire purchase process was easy with no problems at all. It is a great scan tool kit for not much money. Time will tell how it holds up long term but from other members reports they are getting years out of them.

Sorry about the lousy pics.

tech2-01

Credits to @J.Moore (member of corvetteforum.com)

GM Tech2 feedback on what works and what don’t work

  1. VXDIAG VCX Nano for GM reviews:

VXDIAG VCX NANO for GM/OPEL FEATURES:

* Fully compatible with SAE-J2534-1 & SAE-J2534-2
* USB vehicle-to-PC connectivity
* All current and most legacy vehicle protocols: CAN, UART, KW2000, Class2, GM LAN, etc.
* Supports Windows® XP
* CE and FCC compliance for hardware
* Firmware Updatable

1) They now also have software that lets you use your laptop with the same software thats on the Tech 2 unit, it’s called a “GM Nano” ..

The Tech 2 GM Nano for the laptop is $119.00 compared to the Chinese Tech 2 clone which is around $250.00 to $300.00…..

Recently ran into an issue where i wanted to replace my aftermarket pioneer (didn’t like it and much prefer my smart phone) with a stock unit. Found a cheap OEM unit on eBay. After install, i realized that factory head units are tied to the original cars VIN. No problem, i’ll pay the dealership to fix the issue. Only problem they outright say they CANNOT guarantee they can fix the locked status of my radio and i’d still have to pay. As an IT/Network technician, i couldn’t imagine telling people i can’t guarantee i can fix your network or pc problems, but you still owe me full price plus tax.

Enter the VXDIAG VCX Nano. I was looking into clone tech II’s for the past couple weeks and stumbled onto this gem. There is very little info on this product, but i still had more faith in this thing and myself more than my own dealership so i took the plunge. For $119, i basically have the software version of a tech II device. I was able to unlock my radio in a matter of minutes. Have never used a real or upscale scan tool device so i can’t compare but just poking through some of the menus, it looks like i can do anything a tech II can. Kool thing is that the tech2win software runs just fine on my Windows 10 64bit laptop. Would be even cooler with a surface pro or similar tablet. I’m sure there are reasons for owning an actual tech II device over just software, but i wanted to try something different out of curiosity and explore other options for those that want an even cheaper alternative.

vxdiag-nano-for-gm-01
tech2-02
vxdiag-nano-for-gm-03
vxdiag-nano-for-gm-04

Credits to @bgspot (member of corvetteforum.com)

2) Using the VXdiag NANO and tech2win application, I have been able to access every tech2 function including completing a CPS variation relearn, access all abs and airbag troubleshooting functions on my ’99 C5 corvette. I have also been able to access Service Programming System functions using TIS2000 and the vxdiag nano to update the PCM. This is very promising because of the price in comparison to a tech2 clone.

The catch? I don’t think it will work on all GM vehicles. When attempting to interface with my ’97 camaro, I was unable to access the ABS or airbag functions of the tech2, receiving a communications error. I guess my camaro is still old enough where the abs and airbag functions are performed over the OBD1 data bus (although it has an obd2 connector). However, I was able to carry out programming using the tis2000 application and access transmission and drivetrain functions.

How to make the connection between the VCX Nano and the computer:

You plug the device into the OBD2 port, and then you either use Wifi back to the laptop to connect that way ($119), or you can use a usb cable instead ($109).

You have options: USB version & Wifi version

Conclusion:

A used Tech 2 original depends on your budget.

GM Tech2 scanner Chinese is verified been working as a real one for many years, google and you will search many good reviews.

GM VXDiag Nano, based on windows, is verified working fine too and sales at cheap price, the users are supposed to have skills to install the driver, but it’s okay if you follow the video and instruction.

If you are in the market for a tech2 for your C5 corvette, I think you should not purchase a tech2 clone. Instead, go for the MDI clone, or maybe the vxdiag nano if you are willing to risk the fact it seems to be hit or miss depending on the vehicle(s) you plan to interface with.

One other thing to note, if you are intending to do programming, the TIS2000 application has not been updated by GM since 2008. Instead, they now use an alternative online based application called ’tis2web’. While TIS2web has been cracked for the european export GM vehicles, it has not yet been cracked for north american operation GM vehicles. As a result, if you are using a newer vehicle for programming, you will really need to purchase a 3 day subscription to tis2web.

Posted in Car Diagnostic Tool | Tagged , , , | Comments Off on GM TECH2 or GM Nano which is best Troubleshoot the BCM on the 1996 OBD2 Vettes?

The GM TECH 2 and GM MDI Which better ?

According to fobdii.com engineer experience and customers feedback, there are 3 main differences between Chinese GM TECH2 and GM MDI, reading details as follows.

1) Vehicle year coverage:    Chinese GM TECH2 is mainly compatible with the GM vehicles before 2009 year; GM MDI mainly covers GM vehicles after 2009 year.
2) Difference in function: GM tech 2 is a professional GM diagnostic tool; GM MDI support programming online, support Opel offline programming function, Note: if you want to program by using GM MDI, you need to buy account at GM MDI official site at https://www.acdelcotds.com/acdelco/action/subscribehome
3) GM tech 2 is handheld GM scanner, no need to work with computer; GM MDI works with a Laptop, communicate via wired or wireless network.

You may need to know more unique features about GM MDI and GM TECH 2 with TIS2000

GM MDI Features:
1. All Chip are new and original

2. With opel Global tis global diagnostic system

3. Support offline lease function

4. Support programming online

5. Support cable communication

6. Support wireless communication, device have internal wifi card inside.

7. Support Opel offline programming function

8. With GDS2 diagnostic system

9. Tech2win diagnostic software support adding latest software

10. Support original factory latest software

11. With European Chevetl Global tis, Supports European Chevetl offline programming
General Motors Global Electrical Architecture (Global A) and Global Diagnostic Hardware &Software
Global Diagnostic System DGS& Mutiple diagnostic Interface MDI.

Fetures of the GM Tech 2

Tech2 Diagnostic Scan Tool For GM SAAB OPEL SUZUKI Holden ISUZU With 32 MB Card And TIS2000 Software Carton Package

GM TECH2 Scanner Features:

1) GM software in the Tech 2 Flash means the most comprehensive diagnostic software available for late model GM vehicles.
2) Support for on-board diagnostics on all GM systems 1992 thru current year.
3) Removable hardware modules provide insurance against scan tool obsolescence.
4) Large, easy-to-read backlit screen.
5) RS232 & RS485 ports provide the avenue to connect future devices to your Tech 2 Flash.
6) Ability to capture stored DTCs, Freeze Frame, and Failure Record for later review.
7) Ability to view the status of vehicle diagnostic tests as they run.
8) Bi-directional The authentic GM 1992-current year software will provide full bi-directional control when performing power train, chassis, and body diagnostics.

TECH2 Scanner Specifications

1) Microprocessor: 32 bit,16 MHz
2) Memory: 32 MB flash type II PCMCIA. Type III slot available for future expansion.
3) Communications: Integral RS232 communication port.
4) Screen: 3.8.8 backlit monochrome with full graphics capability: 320,40 pixels. Displays up to 9 vehicle parameters at once .Download Tech2 Brochure (5.2 Mb)

An industry change in protocol from OBD II to Controller Area Network (CAN) has begun. In order to perform diagnostics on a vehicle that uses the CAN interface; You will need the Tech 2 Flash and a CAN diagnostic interface module. The module connects between the Tech 2 Flashs diagnostic link cable and the OBD adapter. Once the module is connected, it can be used on all GM vehicle applications,even those vehicles using other platforms such as OBD I and OBD II.

The Tech 2 remains an essential tool through at least the 2010 model year. The GM MDI will not support past models when its diagnostic capabilities are introduced. And, the Tech2 will continue to be needed to diagnose all vehicles from previous model years. Remote programming with the Tech 2 will continue to be supported for use on all 2007 by using TIS 2000 and previous vehicles. Additional information will be supplied in future.

http://www.fobdii.com/wholesale-2-gm-tech2-in-carton-package.html

Posted in Car Diagnostic Tool | Tagged , , | Comments Off on The GM TECH 2 and GM MDI Which better ?

How To Program Honda Insight 2010 Remote Key by Lonsdor K518ISE

Lonsdor k518ISE key programmer has successfully programmed a remote smart key on a Honda Insight year 2010 immobilizer 2.

Lonsdor K518 Highlights:

1.The best car diagnostic tool based on Android
2.WIFI networking ensures software upgrading more convenient
3.No need to plug memory card,or connect the computer with data cable,more flexible in online upgrading,updating and activating.
4.With USB-B2.0 standard connector,OBD-II test cable integrated with the diagnostic connector function of the adapter.
5.Diagnostic speed greatly accelerated,work efficiency improved,better time saving.
6.7 inches high brightness,high definition color IPS capacitive screen
7.3800mAh prolymer battery
8.Support external memory expansion,better within 32G
9.Built-in professional,poerful operation assistant system

Lonsdor K518ISE Auto Key Programmer  Special Features:

Volvo (S40, S60, S80, XC60, XC90, C30, C70, V40, V60, V70) key programming.
Toyota/Lexus: smart key all key lost – via OBD ( without dismantle)
BMW CAS3/CAS3+/CAS3++: direct OBD programming
BMW CAS4/CAS4+: dismantle & read data programming
16 -New Maserati: smart key programming
16 -New Ford: smart key programming
Hyundai / Kia 46/47/8A smart key: PIN code reading via OBD, all key lost included.
Renault ( Megane, Koleos, Scenic) without PIN code key programming
VAG group 4th & 5th immobilizer system
Ferrari (458, F12, F149): direct OBD programming
Peugeot /Citroen: two ways to read PIN code & programming, all keys lost included.

Easy procedure goes below:

Connect K518 host with vehicle via OBD diagnostic socket

Turn on K518ISE

Select Honda->Select by type->Immobilizer->->16 pin->Immo 2->Add a key

lonsdor-k518-honda-insight-1

lonsdor-k518-honda-insight-2

lonsdor-k518-honda-insight-3

lonsdor-k518-honda-insight-4

lonsdor-k518-honda-insight-5

lonsdor-k518-honda-insight-6

Insert registered key and switch ignition on

lonsdor-k518-honda-insight-7

Turn ignition off within 15 sec

lonsdor-k518-honda-insight-8

Turn  ignition switch on

lonsdor-k518-honda-insight-9

Turn ignition off within 17 sec

Switch ignition on with a new key within 20 sec

lonsdor-k518-honda-insight-10

Turn ignition off within 17 sec

Turn ignition on without replacing key within 20 sec

lonsdor-k518-honda-insight-11

Turn ignition off in 15 sec

Turn ignition on

Check if the immobilizer indicator goes off

lonsdor-k518-honda-insight-12

Press YES to continue

Turn ignition off within 15 sec

Turn ignition on

Lonsdor k518ISE identified keys programmed: 4

lonsdor-k518-honda-insight-13

Programming completed.

lonsdor-k518-honda-insight-14

Test the remote and start car.

lonsdor-k518-honda-insight-15

Success.

http://www.fobdii.com

Posted in Auto Key Programmer | Tagged , , | Comments Off on How To Program Honda Insight 2010 Remote Key by Lonsdor K518ISE
